Polyesterimide Self Adhesive Coated Magnet Wire High Tension Strength
| Place of Origin | Zhejiang, China |
|---|---|
| Brand Name | CHINGCUNG |
| Certification | UL/ISO9001/ISO14001/RoHS/Reach |
| Model Number | AISVWY3-1B/220-0.085 |
| Minimum Order Quantity | 20 Kg |
| Price | Negotiation |
| Packaging Details | 5 Kgs each roll, cartons. |
| Delivery Time | 5-7 work days |
| Payment Terms | T/T |
| Supply Ability | 50 tons per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Order No | 30011240085 | Product | Class 220 Self-adhesive Enameled Wire |
|---|---|---|---|
| Film Grade | 1B/2B/GB | Conductor Diameter | 0.085mm |
| Bonding Method | Hot Air | Thermal Class | 220 |
| Advantage | High Tension Strength | Color | Natural Or According To Customers |
| High Light | Self Adhesive Coated Magnet Wire,Polyesterimide Coated Magnet Wire,Class 220 Coated Magnet Wire |
||
Product Description
Hot Air Polyamideimide Composite Polyester Or Polyesterimide Self Adhesive Enameled Copper Winding Wire
Specification range:
0.02~0.9mm Product characteristics: The product has high heat resistance and mechanical properties and good chemical resistance.Application: it is used in the windings of various electric motors and appliances under special circumstances, such as frequent start up and instantaneous load enlarging.
The application of self-adhesive enameled wire in motor windings shows that the motor windings made by self-adhesive enameled wire can meet the technical requirements of the corresponding motor and have reliable performance.Self-adhesive enameled wire can be used to manufacture motor windings, which can omit the process of soaking, save energy, eliminate pollution and reduce labor intensity. It has good technical and economic effect and is worthy of popularization and application.
Our main application fields incude:
High temperature resistant self-bonding wires for aviation; Self-bonding wires for speakersin cars, voice coils, telephones and computers; Self-bondingwires for motors in medical instruments, precision instruments,electric tools, household appliances and robots, etc.
At the same time,we can also customize various.types ofself-bonding enameled wires to meet different national standardsfor customers, according to the technical parameters provided by customers.
Our factory is equipped with automatic manufacturing facilitiesand advanced testing and inspection equipments. We have anumber of patent certificates,strong technical strength.At thesame time, we also have perfect production management system and quality assurance system to maintain the stability and reliability of our products.
Specification:
| Product Name | Class 220 high temperature self-adhesive enameled wire |
| Model Number | AISVWY3-1B/220-0.085 |
| Insulation Material | Polyamideimide composite polyester or polyesterimide enameled |
| Conductor Diameter | 0.085mm |
| Bonding Method | Hot Air |
| Thermal Class | 220 |
| Film Grade | 1B |
| Application | Relays / Transformer / Solenoids Coil / Motor Winding |
FAQ:
Q1:Are you trading company or manufacturer ?
A:We are a manufacturer.
Q2:Are you a factory or a trader?
A:We are the factory, you are welcome to visit our factory.
Q3:How about your company’s annual production capacity?
A:Our Company’s annual production is about 1000 tons.
Q4:How about the quality?
A:We have the best professional engineer and strict QA and QC system. We have the experience of doing the self bonding enameled wires for more than 15 years.
Q5:Can you provide samples? Charge or free?
A:Yes, we can provide samples for payment, which can be sent to you by DHL express or FOB.
